KLA-BEAM 1500P
Ultra-High Power 4 in 1 BSWP
The KLA-BEAM 1500P is a high-output professional lighting fixture engineered for large-scale stages, auditoriums and touring applications. Featuring a powerful 1400W LED light engine, it delivers exceptional brightness with 95 Ra CRI, precise beam, spot, and wash functionality. The fixture incorporates a linear CMY color mixing system for smooth, accurate color transitions, along with advanced optical and framing controls. Designed for reliability and performance, it offers fast, precise movement, sharp projections, and flexible control, making it ideal for demanding professional lighting environments.
KLA-BEAM 1500P product video
- 31,660 Lumens Output, High-brightness performance powered by a 1400W LED engine.
- 5°-50° Zoom Range, Wide and fast zoom coverage, from sharp aerial beams to broad wash looks.
- Linear CMY Color Mixing, Smooth and accurate color blending with rich saturation and consistent output.
- Linear CTO (2700K-6500K), Seamless daylight-to-tungsten color temperature control.
- High CRI Performance, CRI modes up to CRI 95 Ra ensure accurate color reproduction, broadcast, and camera-critical applications.
- Framing Shutter System, Four independently controlled shutters for fast, precise beam shaping and full blackout.
- Rotatable Framing Module, Cutting system rotatable up to 120° for flexible beam orientation.
- Dual Prism System, 4-facet and 6-facet prisms with bi-directional rotation for strong aerial effects.
- Fast, Precise Movement, Rapid pan/tilt with adjustable speed and optical auto-calibration.
- Low-Noise, High-Torque Motors, Ensures quiet operation with fast response, suitable for professional environments.
Specifications
Electrical
| Input Voltage | AC 100-240V, 50/60Hz |
| Power Consumption | 2000W |
Light Source
| Light Engine | 1400W LED light engine |
| Lifespan | 20,000 hours |
| Module Color Temperature | 7500K |
Optics
| Zoom Angle | 5°-50° |
| Aperture | 200 mm |
| Output | 31,640 lm |
| Color Rendering Index (CRI) | CRI1: 74Ra, CRI2: 95Ra |
Control and Programming
| Control Modes | DMX 512, RDM, self-running, master/slave, sound-activated |
| DMX Channels | 38 |
| Setting and Addressing | Control panel with backlit graphic display |
Safety
| Protection Rating | IP20 |
| Minimum Ambient Temperature | 41°F (5°C) |
| Maximum Ambient Temperature | 104°F (40°C) |
| Maximum Surface Temperature | 176°F (80°C) |
Dynamic Effects
| Color Mixing | Linear CMY color mixing system |
| Color Temperature Control | CTO, variable 2700K-6500K |
| Dimming | 0-100% linear dimming |
| Strobe | 1-25 Hz |
| Color Wheel | 1 color wheel with 5 fixed colors |
| Rotating Gobo Wheels | 2 |
| Rotating Gobo Wheel 1 | 6 gobos + open |
| Rotating Gobo Wheel 2 | 6 gobos + open |
| Framing System | 4 shutters rotatable up to 120° |
| Iris | Mechanical linear iris |
| Prism System | 2 |
| Prism 1 | 4-facet prism (bidirectional rotation) |
| Prism 2 | 6-facet prism (bidirectional rotation) |
| Frost Filters | 1 light frost + 1 medium frost |
Movement
| Zoom | Motorized |
| Pan | 540° |
| Tilt | 270° |
Physical
| Dimensions | 832 × 461 × 613 mm |
| Net Weight | 42 kg |
Connections
| AC power input | PowerCon |
| DMX and RDM data in/out | 3-Pin XLR |
