KLA-BEAM 600
High Power 3 in 1 BSW
The KLA-BEAM 600 is a high-performance professional BSW lighting fixture designed for stages, auditoriums, and touring applications. Powered by a 480W high-output LED engine, it delivers intense brightness and long-throw performance with a versatile 3°-45° zoom range, enabling everything from tight aerial beams to broader spot and wash looks. The fixture features an advanced CMY color mixing system with CTO adjustment, complemented by comprehensive gobo and prism effects for creative projection and dynamic mid-air visuals. Engineered for reliability and precision, it offers smooth dimming, fast and accurate pan/tilt movement, and flexible DMX/RDM control, making it a dependable solution for demanding professional lighting environments.
KLA-BEAM 600 product video
- High-output LED engine - Powerful performance driven by a 480W LED light engine
- Wide zoom range (3°-45°) - Smooth transition from tight aerial beams to broader spot and wash looks
- High-intensity output - Delivers up to 128,000 lux at 5 m, ideal for long-throw and high-impact applications
- Advanced color system - Linear CMY color mixing with CTO adjustment, plus a 13-color wheel with white for extended palette control
- Dual gobo system - Fixed gobo wheel with 12 gobos plus open and a rotating gobo wheel with 7 independently rotating glass gobos
- Dual prism effects - Six-linear prism and 8-facet prism with bi-directional rotation
- Precision optical focus - DMX-controlled linear focus for sharp projections across the zoom range
Specifications
Electrical
| Input Voltage | AC 100-240V, 50/60Hz |
| Power Consumption | 600W |
Light Source
| Light Engine | 480W LED light engine |
| Lifespan | 20,000 hours |
| Module Color Temperature | 6000K |
Optics
| Zoom Angle | 3°-45° |
| Aperture | 145 mm |
Control and Programming
| Control Modes | DMX 512, RDM, self-running, master/slave, sound-activated |
| DMX Channels | 25 |
| Setting and Addressing | Control panel with backlit graphic display |
Safety
| Protection Rating | IP20 |
| Minimum Ambient Temperature | 41°F (5°C) |
| Maximum Ambient Temperature | 104°F (40°C) |
| Maximum Surface Temperature | 176°F (80°C) |
Dynamic Effects
| Color Mixing | Linear CMY color mixing system |
| Color Temperature Control | CTO variable 2700K-6500K |
| Dimming | 0-100% linear dimming |
| Strobe | 1-30 Hz |
| Color Wheel | 1 color wheel with 13 colors + white |
| Rotating Gobo Wheel | 1 wheel with 7 rotating gobos |
| Fixed Gobo Wheel | 1 wheel with 12 gobos + open |
| Iris | Mechanical linear iris |
| Prism System | 2 |
| Prism 1 | Six-linear prism (bi-directional rotation) |
| Prism 2 | 8-facet prism (bi-directional rotation) |
| Frost Filters | 1 light frost + 1 medium frost |
Movement
| Zoom | Motorized |
| Pan | 540° |
| Tilt | 270° |
Physical
| Dimensions | 730 x 520 x 389 mm |
| Net Weight | 23.3 kg |
Connections
| AC power input | PowerCon |
| DMX and RDM data in/out | 3 Pin XLR |
