KLA-BEAM 600S
High Power Moving Spot Light
The KLA-BEAM 600S is a high-performance professional lighting fixture designed for stages, auditoriums, studios, and touring applications. Powered by a dual white LED light engine combining pure white and warm white sources, it delivers flexible, high-quality illumination with a CRI up to 95, ensuring natural color reproduction for live and camera-critical environments. With smooth electronic dimming, adjustable high-speed strobe effects, and precise optical control, the fixture supports a wide range of creative lighting looks. Designed for reliability and smooth operation, it features fast, accurate pan and tilt movement and automatic error correction, intelligent thermal management, and multiple control modes, making it a dependable solution for demanding lighting environments.
KLA-BEAM 600S product video
- Dual white LED light engine - Two-in-one pure white + warm white LED engine delivering flexible, high-quality illumination
- Long-life light source - 20,000-hour LED lifespan for low maintenance and long-term reliability
- High CRI performance - Accurate color rendering optimized for broadcast and stage
- Variable color temperature control - Adjustable 3200K-6800K range for seamless tungsten-to-daylight
- Wide zoom range (5°-60°) - Smooth transition from tight beams to wide coverage for versatile stage applications
- Precision optical focus system - High-quality glass lens optics with electronic linear focus
- Intelligent cooling system - Temperature-controlled cooling with smart power and airflow management
- Compact, lightweight construction - Slim form factor designed for easy handling and installation
- Tour-ready protection and safety - IP20 rated with vertical locking system for secure transport and long-term reliability
Specifications
Electrical
| Input Voltage | AC 100-240V, 50/60Hz |
| Power Consumption | 700W |
Light Source
| Light Engine | 300+300W dual LED light engine |
| Lifespan | 20,000 hours |
Optics
| Zoom Angle | 5°-60° |
| Color Rendering Index (CRI) | 95Ra |
Control and Programming
| Control Modes | DMX 512, RDM, self-running, master/slave, sound-activated |
| DMX Channels | 11 |
| Setting and Addressing | Control panel with backlit graphic display |
Safety
| Protection Rating | IP20 |
| Minimum Ambient Temperature | 41°F (5°C) |
| Maximum Ambient Temperature | 104°F (40°C) |
| Maximum Surface Temperature | 176°F (80°C) |
Dynamic Effects
| Color Temperature Control | CTO, variable 2700K-6500K |
| Dimming | 0-100% linear dimming |
| Strobe | 1-20 Hz |
Movement
| Zoom | Motorized |
| Pan | 540° |
| Tilt | 270° |
Physical
| Dimensions | 580 × 430 × 430 mm |
| Net Weight | 12.8 kg |
Connections
| AC power input | PowerCon |
| DMX and RDM data in/out | 3 Pin XLR |
