KLA-FOCAL 400
High-performance LED Profile spotlight
KLA-FOCAL 400 is a high-output professional LED profile spotlight designed for theatres, auditoriums, House of Worship, and stage lighting applications requiring precise beam control and high-quality white light. Powered by a 400W COB LED light source, it delivers strong illumination with excellent color rendering (CRI ≥90) and 3200K to 5600K color temperature options. The fixture features manual focus and adjustable beam angle from 15°–40°, allowing flexible control for spot, flood, and soft-edge lighting effects. Built with professional optical lenses and reliable DMX control, it provides smooth dimming performance and consistent output, making it suitable for demanding professional lighting environments.
- High-output 400W LED engine – Delivers powerful, consistent light for stage and theatrical applications
- Variable color temperature – Adjustable from 3200K to 5600K
- High color rendering – CRI ≥90 ensures accurate color reproduction for stage and broadcast lighting
- Adjustable beam angle – 15°–40° optical zoom allows precise beam shaping.
- Manual focus control – Enables accurate beam adjustment for different lighting requirements
- Smooth dimming performance – 0–100% linear dimming
- Multiple lighting effects – Supports spot, flood, and soft-edge illumination modes
Specifications
Electrical
| Input Voltage | AC 100–240V, 50/60Hz |
| Power Consumption | 400W |
Light Source
| Main Light Source | 400W CW+WW LED Engine |
| Lifespan | 10,000 hours |
| CRI | >90 Ra |
| Beam angle | 15° - 40° |
Control and Programming
| Control Modes | DMX 512, RDM, self-running, master/slave |
| DMX Channels | 2 |
| Setting and Addressing | Control panel with display |
Safety
| Protection Rating | IP20 |
| Minimum Ambient Temperature | 41°F (5°C) |
| Maximum Ambient Temperature | 104°F (40°C) |
| Maximum Surface Temperature | 176°F (80°C) |
Dynamic Effects
| Color Mixing | 3200K to 5600K linear temperature adjustment |
| Dimming | 0–100% linear dimming |
| Effect Modes | Spot, flood, and soft-edge illumination |
Physical
| Dimensions | 303 × 243 × 765 mm |
| Net Weight | 14 kg |
Connections
| AC power input | PowerCon |
| DMX and RDM data in/out | 3 Pin XLR |
